BC848CWH6327XTSA1
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 30 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 420@2mA@5V |
| Maximum Operating Frequency: | 250(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 30 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
更新于 2026-03-062N6517CTA
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 400 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 20@1mA@10V|30@10mA@10V|30@30mA@10V|20@50mA@10V|15@100mA@10V|50@5mA@10V |
| Maximum Operating Frequency: | 200 MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.3@1mA@10mA|0.35@2mA@20mA|0.5@3mA@30mA|1@5mA@50mA V |
| Maximum Collector Base Voltage: | 400 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
BC848CDW1T1
电气特性 Features
| Type: | NPN |
| Pin Count: | 6 |
| Maximum Collector Emitter Voltage: | 30 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 420@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 30 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 380 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2SC5242OTU
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 250 V |
| Maximum DC Collector Current: | 17 A |
| Minimum DC Current Gain: | 80@1A@5V |
| Maximum Operating Frequency: | 30(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 3@0.8A@8A V |
| Maximum Collector Base Voltage: | 250 V |
| Operating Temperature: | -50 to 150 ℃ |
| Maximum Power Dissipation: | 130000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2N4401TA
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 40 V |
| Maximum DC Collector Current: | 0.6 A |
| Minimum DC Current Gain: | 20@0.1mA@1V|40@1mA@1V|80@10mA@1V|100@150mA@1V|40@500mA@2V |
| Maximum Operating Frequency: | 250(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.4@15mA@150mA|0.75@50mA@500mA V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
BC849BW,115
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 30 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 30 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 200 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC549BTF
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 30 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 300(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 30 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 500 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2PB710ARL,215
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 40@0.5A@10V|120@0.15A@10V |
| Maximum Operating Frequency: | 120(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.6@30mA@300mA V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2N5551BU
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 160 V |
| Maximum DC Collector Current: | 0.6 A |
| Minimum DC Current Gain: | 80@1mA@5V|80@10mA@5V|30@50mA@5V |
| Maximum Operating Frequency: | 300 MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.15@1mA@10mA|0.2@5mA@50mA V |
| Maximum Collector Base Voltage: | 180 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2SA2126-TL-H
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 3 A |
| Minimum DC Current Gain: | 200@100mA@2V |
| Maximum Operating Frequency: | 390(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.27@50mA@1A|0.52@100mA@2A V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 800 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC817W,115
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 100@100mA@1V|40@500mA@1V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.7@50mA@500mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 200 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC51-16PA,115
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 1 A |
| Minimum DC Current Gain: | 100@150mA@2V |
| Maximum Operating Frequency: | 145(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.5@50mA@500mA V |
| Maximum Collector Base Voltage: | 45 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1650 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2PD601ASL,215
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 90@0.1A@2V|290@2mA@10V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@10mA@100mA V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2SA1706T-AN
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 2 A |
| Minimum DC Current Gain: | 200@100mA@2V |
| Maximum Operating Frequency: | 150(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.7@50mA@1A V |
| Maximum Collector Base Voltage: | 60 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
BC639RL1G
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 80 V |
| Maximum DC Collector Current: | 1 A |
| Minimum DC Current Gain: | 25@5mA@2V|40@150mA@2V|25@500mA@2V |
| Maximum Operating Frequency: | 200(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.5@50mA@500mA V |
| Maximum Collector Base Voltage: | 80 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
