2N5684G
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 80 V |
| Maximum DC Collector Current: | 50 A |
| Minimum DC Current Gain: | 15@25A@2V|5@50A@5V |
| Maximum Operating Frequency: | 2(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 1@2.5A@25A|5@10A@50A V |
| Maximum Collector Base Voltage: | 80 V |
| Operating Temperature: | -65 to 200 ℃ |
| Maximum Power Dissipation: | 300000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
更新于 2025-12-27BC850BW,115
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 200 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2N5401RLRAG
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 150 V |
| Maximum DC Collector Current: | 0.6 A |
| Minimum DC Current Gain: | 50@1mA@5V|60@10mA@5V|50@50mA@5V |
| Maximum Operating Frequency: | 300 MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.2@1mA@10mA|0.5@5mA@50mA V |
| Maximum Collector Base Voltage: | 160 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
BC557BTF
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 150(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.3@0.5mA@10mA|0.65@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 500 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2SD1815T-E
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 100 V |
| Maximum DC Collector Current: | 3 A |
| Minimum DC Current Gain: | 200@0.5A@5V |
| Maximum Operating Frequency: | 130(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.5@0.15A@1.5A V |
| Maximum Collector Base Voltage: | 120 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2SC6098-TL-E
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 80 V |
| Maximum DC Collector Current: | 2.5 A |
| Minimum DC Current Gain: | 300@100mA@5V |
| Maximum Operating Frequency: | 350(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.165@50mA@1A|0.15@100mA@1A V |
| Maximum Collector Base Voltage: | 120 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 800 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC807-40,215
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 250@100mA@1V|40@500mA@1V |
| Maximum Operating Frequency: | 80(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.7@50mA@500mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC847CWH6327XTSA1
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 420@2mA@5V |
| Maximum Operating Frequency: | 250(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2SC5706-H
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 5 A |
| Minimum DC Current Gain: | 200@500mA@2V |
| Maximum Operating Frequency: | 400(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.135@50mA@1A|0.24@100mA@2A V |
| Maximum Collector Base Voltage: | 100 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 800 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
2SA2112-AN
电气特性 Features
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 50 V |
| Maximum DC Collector Current: | 3 A |
| Minimum DC Current Gain: | 200@100mA@2V |
| Maximum Operating Frequency: | 390(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.27@50mA@1A|0.7@100mA@2A V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
BC847QASX
电气特性 Features
| Type: | NPN |
| Pin Count: | 6 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Collector Emitter Saturation Voltage: | 0.1@0.5mA@10mA|0.3@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 350 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BC850BW,135
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.25@0.5mA@10mA|0.6@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 200 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
2SC5566-TD-E
电气特性 Features
| Type: | NPN |
| Pin Count: | 4 |
| Maximum Collector Emitter Voltage: | 100 V |
| Maximum DC Collector Current: | 4 A |
| Minimum DC Current Gain: | 200@500mA@2V |
| Maximum Operating Frequency: | 400(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.13@50mA@1A|0.225@100mA@2A V |
| Maximum Collector Base Voltage: | 100 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1300 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
15GN03MA-TL-E
电气特性 Features
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 10 V |
| Maximum DC Collector Current: | 0.07 A |
| Minimum DC Current Gain: | 100@10mA@5V |
| Maximum Operating Frequency: | 1500(Typ) MHz |
| Maximum Collector Base Voltage: | 20 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 400 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
