VS-ST1230C12K0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 1745 A |
| Surge Current Rating: | 35100 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 1.62@4000A V |
| Repetitive Peak Off-State Current: | 100 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
更新于 2025-09-16VS-ST280C06C1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 600 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 500 A |
| Surge Current Rating: | 8220 A |
| Repetitive Peak Forward Blocking Voltage: | 600 V |
| Peak On-State Voltage: | 1.36@1050A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-40TPS08PBF
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 150 mA |
| Rated Average On-State Current: | 35 A |
| Surge Current Rating: | 600 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.85@110A V |
| Repetitive Peak Off-State Current: | 0.5 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Through Hole |
| Rad Hard: | No |
TISP7180F3DR-S
电气特性 Features
| Type: | TSPD |
| Repetitive Peak Reverse Voltage: | 145 V |
| Maximum Holding Current: | 150(Min) mA |
| Surge Current Rating: | 4.3 A |
| Repetitive Peak Forward Blocking Voltage: | 145 V |
| Peak On-State Voltage: | 5@5A V |
| Repetitive Peak Off-State Current: | 0.01 mA |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
VS-ST303C12LFH0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 515 A |
| Surge Current Rating: | 8320 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 2.16@1255A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-2N682
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 50 V |
| Maximum Holding Current: | 20 mA |
| Rated Average On-State Current: | 16 A |
| Surge Current Rating: | 180 A |
| Repetitive Peak Forward Blocking Voltage: | 50 V |
| Peak On-State Voltage: | 2@16A V |
| Repetitive Peak Off-State Current: | 6.5 mA |
| Maximum Gate Trigger Voltage: | 2 V |
| Maximum Gate Trigger Current: | 40 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
VS-ST103S08PFN1
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 105 A |
| Surge Current Rating: | 3150 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.73@300A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
VS-VSKH136/08PBF
电气特性 Features
| Type: | SCR Module |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 200 mA |
| Rated Average On-State Current: | 135 A |
| Surge Current Rating: | 3360 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.57 V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST733C08LFM0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 940 A |
| Surge Current Rating: | 20950 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.63@1700A V |
| Repetitive Peak Off-State Current: | 75 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-VSKL105/04
电气特性 Features
| Type: | SCR Module |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 250 mA |
| Rated Average On-State Current: | 105 A |
| Surge Current Rating: | 2094 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 1.8 V |
| Repetitive Peak Off-State Current: | 20 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 130 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-10RIA100
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1000 V |
| Maximum Holding Current: | 130 mA |
| Rated Average On-State Current: | 10 A |
| Surge Current Rating: | 240 A |
| Repetitive Peak Forward Blocking Voltage: | 1000 V |
| Peak On-State Voltage: | 1.75@32A V |
| Repetitive Peak Off-State Current: | 10 mA |
| Maximum Gate Trigger Voltage: | 2 V |
| Maximum Gate Trigger Current: | 60 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -65 to 125 ℃ |
| Mounting: | Stud |
VS-ST230S12P1VPBF
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 230 A |
| Surge Current Rating: | 5970 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 1.55@720A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
VS-50RIA100
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1000 V |
| Maximum Holding Current: | 200 mA |
| Rated Average On-State Current: | 50 A |
| Surge Current Rating: | 1490 A |
| Repetitive Peak Forward Blocking Voltage: | 1000 V |
| Peak On-State Voltage: | 1.6@157A V |
| Repetitive Peak Off-State Current: | 15 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 100 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
VS-ST700C20L1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 2000 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 910 A |
| Surge Current Rating: | 16400 A |
| Repetitive Peak Forward Blocking Voltage: | 2000 V |
| Peak On-State Voltage: | 1.8@2000A V |
| Repetitive Peak Off-State Current: | 80 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TISP7260F3PS
电气特性 Features
| Type: | TSPD |
| Repetitive Peak Reverse Voltage: | 200 V |
| Maximum Holding Current: | 150(Min) mA |
| Surge Current Rating: | 5.7 A |
| Repetitive Peak Forward Blocking Voltage: | 200 V |
| Peak On-State Voltage: | 5@5A V |
| Repetitive Peak Off-State Current: | 0.01 mA |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Through Hole |
| Rad Hard: | No |
