SMV1249-003LF
电气特性 Features
| Configuration: | Dual Common Anode |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 11 |
| Maximum Reverse Voltage: | 15 V |
| Minimum Diode Capacitance: | 28@0.3V pF |
| Minimum Quality Factor: | 600(Typ) |
| Tuning Ratio Test Condition: | 0.3/4.7 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
更新于 2025-07-07SMV1245-011LF
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 3.5 |
| Maximum Reverse Voltage: | 26 V |
| Minimum Diode Capacitance: | 4.4@1V pF |
| Tuning Ratio Test Condition: | 1/9 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY57-02W H6327
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO|VCXO|TCXO |
| Minimum Tuning Ratio: | 3 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 16.5@1V pF |
| Tuning Ratio Test Condition: | 1/4 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
1SV284TPH3
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF|UHF |
| Type: | VCO |
| Minimum Tuning Ratio: | 1.8 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 15@1V pF |
| Tuning Ratio Test Condition: | 1/4 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
SMV1251-011LF
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 11 |
| Maximum Reverse Voltage: | 15 V |
| Minimum Diode Capacitance: | 38@0.3V pF |
| Minimum Quality Factor: | 400(Typ) |
| Tuning Ratio Test Condition: | 0.3/4.7 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BB639E7904HTSA1
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF |
| Type: | Tuner |
| Minimum Tuning Ratio: | 13.5 |
| Maximum Reverse Voltage: | 30 V |
| Minimum Diode Capacitance: | 36@1V pF |
| Tuning Ratio Test Condition: | 1/28 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BB156,115
电气特性 Features
| Configuration: | Single |
| Applications Type: | VCO |
| Minimum Tuning Ratio: | 2.7 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 14.4@1V pF |
| Tuning Ratio Test Condition: | 1/7.5 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY40,215
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF |
| Type: | Tuner |
| Minimum Tuning Ratio: | 5 |
| Maximum Reverse Voltage: | 30 V |
| Minimum Diode Capacitance: | 26@3V pF |
| Tuning Ratio Test Condition: | 3/25 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
1SV270(TPH3,F)
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | UHF |
| Type: | VCO |
| Minimum Tuning Ratio: | 1.8 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 15@1V pF |
| Tuning Ratio Test Condition: | 1/4 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
ZC934ATA
电气特性 Features
| Configuration: | Single |
| Applications Type: | VCXO|TCXO |
| Maximum Reverse Voltage: | 12 V |
| Minimum Diode Capacitance: | 95@1V pF |
| Minimum Quality Factor: | 80 |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BB181,335
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF |
| Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 12 |
| Maximum Reverse Voltage: | 30 V |
| Minimum Diode Capacitance: | 8@0.5V pF |
| Tuning Ratio Test Condition: | 0.5/28 V |
| Mounting: | Surface Mount |
SMV1215-001
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 5(Typ) |
| Maximum Reverse Voltage: | 12 V |
| Minimum Diode Capacitance: | 8.7@1V pF |
| Tuning Ratio Test Condition: | 1/4 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY53-02V H6327
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 1.8 |
| Maximum Reverse Voltage: | 6 V |
| Minimum Diode Capacitance: | 4.8@1V pF |
| Tuning Ratio Test Condition: | 1/3 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
1SV282(TPH3,F)
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner |
| Minimum Tuning Ratio: | 12 |
| Maximum Reverse Voltage: | 34 V |
| Minimum Diode Capacitance: | 33@2V pF |
| Tuning Ratio Test Condition: | 2/25 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
SMV1251-079LF
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 11 |
| Maximum Reverse Voltage: | 15 V |
| Minimum Diode Capacitance: | 38@0.3V pF |
| Minimum Quality Factor: | 400(Typ) |
| Tuning Ratio Test Condition: | 0.3/4.7 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
