SMP1307-006LF
电气特性 Features
| Configuration: | Dual Series |
| Maximum Reverse Voltage: | 200 V |
| Maximum Forward Voltage: | 0.85(Typ)@10mA V |
| Frequency Range: | HF|VHF|UHF |
| Maximum Diode Capacitance: | 0.3@30V pF |
| Maximum Power Dissipation: | 250 mW |
| Typical Carrier Life Time: | 1.5 us |
| Mounting: | Surface Mount |
| Type: | Attenuator|Switch |
| Rad Hard: | No |
更新于 2025-12-27BAP64-04
电气特性 Features
- 类型: 开关二极管
- Pd = 350mW
- Io = 150mA
- Vr = 75V
- Vf = 1.25V
- Ir = 1uA
- Trr = 4ns
- 内部电路图:
更多相似二极管产品参数说明表
BA782S-GS18
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 35 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1 V |
| Frequency Range: | VHF|UHF |
| Maximum Diode Capacitance: | 1.25@3V pF |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
BAP70-02,115
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 50 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1.1@50mA V |
| Frequency Range: | VHF |
| Maximum Diode Capacitance: | 0.25@20V pF |
| Maximum Power Dissipation: | 415 mW |
| Typical Carrier Life Time: | 1.25 us |
| Mounting: | Surface Mount |
| Type: | Attenuator |
| Rad Hard: | No |
1SS356TW11
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 35 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1@10mA V |
| Maximum Diode Capacitance: | 1.2@6V pF |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
SMP1340-040LF
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 50 V |
| Maximum Forward Voltage: | 0.85(Typ)@10mA V |
| Frequency Range: | HF|VHF|UHF|SHF |
| Maximum Diode Capacitance: | 0.3@5V pF |
| Maximum Power Dissipation: | 250 mW |
| Typical Carrier Life Time: | 0.1 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
HSMP-3820-TR1G
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 50 V |
| Frequency Range: | UHF |
| Maximum Diode Capacitance: | 0.8@20V pF |
| Typical Carrier Life Time: | 0.07 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
BAR6302VH6327XTSA1
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 50 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1.2 V |
| Frequency Range: | SHF |
| Maximum Diode Capacitance: | 0.3@5V pF |
| Maximum Power Dissipation: | 250 mW |
| Typical Carrier Life Time: | 0.075 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
BA479S-TAP
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 30 V |
| Maximum Forward Current: | 50 mA |
| Maximum Forward Voltage: | 1@20mA V |
| Frequency Range: | HF|VHF|UHF |
| Maximum Diode Capacitance: | 0.5@0V pF |
| Typical Carrier Life Time: | 4 us |
| Mounting: | Through Hole |
| Type: | Attenuator |
| Rad Hard: | No |
HSMP-389T-TR1G
电气特性 Features
| Configuration: | Single Dual Anode Quad Cathode |
| Maximum Reverse Voltage: | 100 V |
| Maximum Diode Capacitance: | 0.3@5V pF |
| Typical Carrier Life Time: | 0.2 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
HSMP-3812-TR1G
电气特性 Features
| Configuration: | Dual Series |
| Maximum Reverse Voltage: | 100 V |
| Maximum Diode Capacitance: | 0.35@50V pF |
| Typical Carrier Life Time: | 1.5 us |
| Mounting: | Surface Mount |
| Type: | Attenuator |
| Rad Hard: | No |
HSMP-3813-BLKG
电气特性 Features
| Configuration: | Dual Common Anode |
| Maximum Reverse Voltage: | 100 V |
| Maximum Diode Capacitance: | 0.35@50V pF |
| Typical Carrier Life Time: | 1.5 us |
| Mounting: | Surface Mount |
| Type: | Attenuator |
| Rad Hard: | No |
HSMP-389C-BLKG
电气特性 Features
| Configuration: | Dual Series |
| Maximum Reverse Voltage: | 100 V |
| Maximum Diode Capacitance: | 0.3@5V pF |
| Typical Carrier Life Time: | 0.2 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
BAR8802LRHE6327XTSA1
电气特性 Features
| Configuration: | Single |
| Maximum Reverse Voltage: | 80 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1.2 V |
| Frequency Range: | UHF |
| Maximum Diode Capacitance: | 0.4@1V pF |
| Maximum Power Dissipation: | 250 mW |
| Typical Carrier Life Time: | 0.5 us |
| Mounting: | Surface Mount |
| Type: | Switch |
| Rad Hard: | No |
BAR64V-05W-V-GS18
电气特性 Features
| Configuration: | Dual Common Cathode |
| Maximum Reverse Voltage: | 100 V |
| Maximum Forward Current: | 100 mA |
| Maximum Forward Voltage: | 1.1@50mA V |
| Frequency Range: | HF|VHF|UHF|SHF |
| Maximum Diode Capacitance: | 0.35@20V pF |
| Typical Carrier Life Time: | 1.8 us |
| Type: | Attenuator|Switch |
| Rad Hard: | No |
