VS-ST700C18L0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 910 A |
| Surge Current Rating: | 16400 A |
| Repetitive Peak Forward Blocking Voltage: | 1800 V |
| Peak On-State Voltage: | 1.8@2000A V |
| Repetitive Peak Off-State Current: | 80 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
更新于 2026-05-01VS-VSKH26/08
电气特性 Features
| Type: | SCR Module |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 200 mA |
| Rated Average On-State Current: | 27 A |
| Surge Current Rating: | 420 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.65 V |
| Repetitive Peak Off-State Current: | 15 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST300C12L1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 560 A |
| Surge Current Rating: | 8380 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 2.18@1635A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TISP7180F3DR-S
电气特性 Features
| Type: | TSPD |
| Repetitive Peak Reverse Voltage: | 145 V |
| Maximum Holding Current: | 150(Min) mA |
| Surge Current Rating: | 4.3 A |
| Repetitive Peak Forward Blocking Voltage: | 145 V |
| Peak On-State Voltage: | 5@5A V |
| Repetitive Peak Off-State Current: | 0.01 mA |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
VS-ST380C06C0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 600 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 960 A |
| Surge Current Rating: | 15700 A |
| Repetitive Peak Forward Blocking Voltage: | 600 V |
| Peak On-State Voltage: | 1.6@3000A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST330S08P1PBF
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 330 A |
| Surge Current Rating: | 9420 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.52@1000A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
TN1205T-600B-TR
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 600 V |
| Maximum Holding Current: | 15 mA |
| Rated Average On-State Current: | 8 A |
| Surge Current Rating: | 120 A |
| Repetitive Peak Forward Blocking Voltage: | 600 V |
| Peak On-State Voltage: | 1.6@24A V |
| Repetitive Peak Off-State Current: | 0.005 mA |
| Maximum Gate Trigger Voltage: | 1.3 V |
| Maximum Gate Trigger Current: | 5 mA |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
TS110-8A1-AP
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 700 V |
| Maximum Holding Current: | 12 mA |
| Rated Average On-State Current: | 1.25@Tl=53C A |
| Surge Current Rating: | 21 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.6@2.5V V |
| Maximum Gate Trigger Voltage: | 0.8 V |
| Maximum Gate Trigger Current: | 0.1 mA |
| Maximum Gate Peak Inverse Voltage: | 7.5(Min) V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Through Hole |
| Rad Hard: | No |
VS-ST780C04L0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 1350 A |
| Surge Current Rating: | 25600 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 1.31@3600A V |
| Repetitive Peak Off-State Current: | 80 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST230C12C1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 410 A |
| Surge Current Rating: | 5970 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 1.69@880A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST780C04L1L
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 1350 A |
| Surge Current Rating: | 25600 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 1.31@3600A V |
| Repetitive Peak Off-State Current: | 80 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST180C08C0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 350 A |
| Surge Current Rating: | 5230 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.96@750A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST700C12L0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 910 A |
| Surge Current Rating: | 16400 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 1.8@2000A V |
| Repetitive Peak Off-State Current: | 80 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST303S04PFN0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 300 A |
| Surge Current Rating: | 8320 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 2.16@1255A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
TN805-600B-TR
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 600 V |
| Maximum Holding Current: | 25 mA |
| Rated Average On-State Current: | 5 A |
| Surge Current Rating: | 73 A |
| Repetitive Peak Forward Blocking Voltage: | 600 V |
| Peak On-State Voltage: | 1.6@16A V |
| Repetitive Peak Off-State Current: | 0.005 mA |
| Maximum Gate Trigger Voltage: | 1.3 V |
| Maximum Gate Trigger Current: | 5 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
