TYN610RG
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 600 V |
| Maximum Holding Current: | 30 mA |
| Rated Average On-State Current: | 6.4 A |
| Surge Current Rating: | 105 A |
| Repetitive Peak Forward Blocking Voltage: | 600 V |
| Peak On-State Voltage: | 1.6@20A V |
| Repetitive Peak Off-State Current: | 0.01 mA |
| Maximum Gate Trigger Voltage: | 1.5 V |
| Maximum Gate Trigger Current: | 15 mA |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Through Hole |
| Rad Hard: | No |
更新于 2025-12-27VS-ST330C14C1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1400 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 720 A |
| Surge Current Rating: | 9420 A |
| Repetitive Peak Forward Blocking Voltage: | 1400 V |
| Peak On-State Voltage: | 1.96@1810A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TN22-1500T
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 175(Min) mA |
| Rated Average On-State Current: | 1.8 A |
| Surge Current Rating: | 22 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 3.1@2A V |
| Repetitive Peak Off-State Current: | 0.1 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 1.5 mA |
| Operating Temperature: | -40 to 110 ℃ |
| Mounting: | Through Hole |
| Rad Hard: | No |
VS-ST180S08P0V
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 200 A |
| Surge Current Rating: | 5230 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.75@570A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
VS-VSKH230-12PBF
电气特性 Features
| Type: | SCR Module |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 500 mA |
| Rated Average On-State Current: | 230 A |
| Surge Current Rating: | 7850 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 1.59 V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 130 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST333S08PFL0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 330 A |
| Surge Current Rating: | 11520 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.96@1810A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
VS-T90RIA20
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 200 V |
| Maximum Holding Current: | 200 mA |
| Rated Average On-State Current: | 90 A |
| Surge Current Rating: | 1870 A |
| Repetitive Peak Forward Blocking Voltage: | 200 V |
| Peak On-State Voltage: | 1.55 V |
| Repetitive Peak Off-State Current: | 0.1 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 120 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
VS-ST300C04C1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 400 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 650 A |
| Surge Current Rating: | 8380 A |
| Repetitive Peak Forward Blocking Voltage: | 400 V |
| Peak On-State Voltage: | 2.18@1635A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST173C10CFP0
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1000 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 330 A |
| Surge Current Rating: | 4900 A |
| Repetitive Peak Forward Blocking Voltage: | 1000 V |
| Peak On-State Voltage: | 2.07@600A V |
| Repetitive Peak Off-State Current: | 40 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST1200C20K0L
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 2000 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 1650 A |
| Surge Current Rating: | 32000 A |
| Repetitive Peak Forward Blocking Voltage: | 2000 V |
| Peak On-State Voltage: | 1.73@4000A V |
| Repetitive Peak Off-State Current: | 100 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST300C20L1
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 2000 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 560 A |
| Surge Current Rating: | 8380 A |
| Repetitive Peak Forward Blocking Voltage: | 2000 V |
| Peak On-State Voltage: | 2.18@1635A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST180S16P0
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1600 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 200 A |
| Surge Current Rating: | 5230 A |
| Repetitive Peak Forward Blocking Voltage: | 1600 V |
| Peak On-State Voltage: | 1.75@570A V |
| Repetitive Peak Off-State Current: | 30 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Stud |
| Rad Hard: | No |
VS-ST300C18C1L
电气特性 Features
| Type: | PCT |
| Repetitive Peak Reverse Voltage: | 1800 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 650 A |
| Surge Current Rating: | 8380 A |
| Repetitive Peak Forward Blocking Voltage: | 1800 V |
| Peak On-State Voltage: | 2.18@1635A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-VSKL136/08PBF
电气特性 Features
| Type: | SCR Module |
| Repetitive Peak Reverse Voltage: | 800 V |
| Maximum Holding Current: | 200 mA |
| Rated Average On-State Current: | 135 A |
| Surge Current Rating: | 3360 A |
| Repetitive Peak Forward Blocking Voltage: | 800 V |
| Peak On-State Voltage: | 1.57 V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 2.5 V |
| Maximum Gate Trigger Current: | 150 mA |
| Maximum Gate Peak Inverse Voltage: | 10 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VS-ST303C12CFK1
电气特性 Features
| Type: | SCR |
| Repetitive Peak Reverse Voltage: | 1200 V |
| Maximum Holding Current: | 600 mA |
| Rated Average On-State Current: | 620 A |
| Surge Current Rating: | 8320 A |
| Repetitive Peak Forward Blocking Voltage: | 1200 V |
| Peak On-State Voltage: | 2.16@1255A V |
| Repetitive Peak Off-State Current: | 50 mA |
| Maximum Gate Trigger Voltage: | 3 V |
| Maximum Gate Trigger Current: | 200 mA |
| Maximum Gate Peak Inverse Voltage: | 5 V |
| Operating Temperature: | -40 to 125 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
